Atlas
Discovery
20 Discovery
The Duckworth 20 Discovery boat redefines what angling families seek in a versatile marine craft.
This vessel is designed to navigate a variety of aquatic environments with ease and bring its passengers back to shore safely after a day of adventure. Boasting the broadest extended transom in its category, the Duckworth 20 Discovery ensures that everyone aboard is cradled within the safety of a full-height transom, complemented by the most spacious fishing cockpit in its class.
While many boats can navigate multiple water types, the 20 Discovery is a cut above the rest—with its robust extended transom, encompassing gunwale, and deep-v hull, it stands as the ultimate safe and multi-functional maritime tool for families who cast their lines in pursuit of more than just fish, but memorable experiences as well. Choose from a full hardtop for complete protection, a semi-hardtop for a balance of shelter and openness, or a soft top for enjoying the sun and breeze.
Specifications
| Length (including bracket) | 22′ 11″ / 6.99m |
|---|---|
| Beam | 8′ 2″ / 2.49m |
| Side | 0.125″ / 3.175mm (5052-H32) |
| Height of Sides | 38″ / 96.52cm |
| Bottom | 0.190″ / 4.83mm (5086-H116) |
| Bottom Width | 6′ 5″ / 1.98m |
| Dry Weight | 2220 lbs. / 988kg |
| Fuel | 65 USG /246.1L diurnal fuel system |
| Deadrise | Bow 30°, Forward 24°, Transom 14° |
| Max HP Rating | 225HP / 168kw |
| Maximum Capacities | 6 person or 990lbs, 450 kg 2220lbs (1007kg) motor, persons, gear |
Build Your Own Duckworth
Customize your boat how you want it.
Deadrise
STANDARD FEATURES
Hull Features
- 25″ Single engine offshore bracket with integral bottom sheet and full width swim platform
- Extruded chine, toe rail, keel strip & gunwale
- Full reverse chine bottom design
- 5 piece welded, walkthrough windshield with grab handles
- Recessed self bailing diamond tread bow
- Bow storage box with anchor rope cutout
- 3″ polished bow & stern rails
- Bow storage (Room for 2nd battery)
- Passenger console tray w/grab handle
- Fisherman’s transom with fish box, self draining utility area, 2-piece cutting board hatch lid and framed rigging access panels
- Side storage trays with gunwale rod racks – 2 per side
- Welded double bow eye
- 2 – welded stern eyes
- 5 – 8″ welded cleats
- Pressure tested subfloor fuel cell – diurnal system compliant
- Transducer brackets
- Trim tab brackets
Exterior Features
- Choice of standard paint colors
- Top, gunwales and deck granite paint
- 1/2 side and transom paint with vinyl graphics
- Zinc anodes – 2x
Interior Features
- Standard folding seats on fixed-height pedestals w/ locking seat swivels
- 26″ Rear bench seats w/back rest
- Heavy duty convertible top with side curtains
- Backdrop curtain
- Vinyl covered marine grade plywood floors and kick panels
- Stainless steel cup holders
- Carpeted Sidewalls
- Netted Storage
- Rear transom storage
- Sub floor storage
Rigging Options
- Anti-feedback steering
- Instrument panel w/ fuel gauge and USB port
- LED Navigation lights and anchor lights
- Stainless steel marine horn
- Bilge pump
- Fuel water separator
- Single Battery Switch only (No Battery)
